Expanding on our line of individual bale wrappers the TL360 brings high speed in the field wrapping to round bale producers.

The self-loading design allows you wrap on the go while following the baler. The loading arm allows operators to carry a second bale while one is being wrapped.

A cut and hold system ensures that the film is always ready for the next bale while an optional bale tipper lays the bale on its side for easy handling with a grapple.

Control Panel

Control Panel

An intuitive control panel is mounted to the TL360 for easy control when you’re not in the tractor.

Twin Wrap Kit Feature Image

Tongue Lock

A tongue lock secures the tongue while the wrapper is in the transport or wrapping position.

Twin Wrap Kit Feature Image

Cut and Hold

The cut and hold system ensures that the plastic is secured and ready for new bale that enters the wrapper.

Bale Adjustment

Bale Guides

Adjustable bale guides on the loading arm and wrapping chamber allow the TL360 to accomodate 4' or 5' bales.

Other Standard Features

  • Safety switches on doors
  • Shut off Switch on the machine
  • Electronic Control Valves
  • Fully automatic Cycling
  • Precision wrapping
  • Two 30” pre-tensioners
  • Soft start (Hoop)
  • Automatic Cut/Hold
  • Bale Counter- Lifetime bale count
  • Bale Counter – Resettable
  • Self-Diagnostic controls
  • 12 button individual function controls
  • In-cab full function control
  • Easy to read display with RAM mount
  • Plugs into 12 Volt power outlet
  • High-pressure filter (Filter contamination)
Specifications TL360
Unit Type Trailed, Self-Loading
Height 133"
Width 119"
Length 164"
Weight 5,100 lbs.
Bale Sizes 4' x 5.5' diameter
5' x 4.5 diameter
Tractor HP 60HP
Hydraulic Requirement 16 GPM
Hitch Type Clevis
Twin Wrap Kit Feature Image

Twin Wrap Kit

The Twin Wrap Kit simultaneously pulls film from two rolls laminating them together to increase the strength of the film which aids in bending over stubborn stems.

L E D Working Lights Option Image

LED Working Lights

Available LED work lights help to increase safety when working in low light conditions.

Twin Wrap Kit Feature Image

Bale Tipper

The optional tipper gently deflects the bale causing it to land on its side. Placing it in the ideal position for handling with a grapple.

Remote Control Kit for Stationary Wrapping Option Image

Remote Control Kit for Stationary Wrapping

Allows operators to start and stop cycles when the TL360 is being used stationary and an operator is placing/removing bales with another tractor.

  • Arm & Finger Overview Video

    Arm & Finger Overview

  • Control Panel Overview Video

    Control Panel Overview

  • Cut & Hold Overview Video

    Cut & Hold Overview

  • Bumper Tail Overview Video

    Bumper Tail Overview

  • Sensor Overview

    Sensor Overview

  • Display Panel Overview Video

    Display Panel Overview

  • Converting Unit for 5ft Bales Video

    Converting Unit for 5ft Bales

  • Hoop Overview Video

    Hoop Overview

  • Tongue Overview Video

    Tongue Overview

  • Full Unit Overview Video

    Full Unit Overview

Errors and omissions excepted. Specifications and images on this page are subject to change without notice. For current information on all of our products, please contact Tubeline Manufacturing.
