The Nitro LS series spreaders are ideal for farms with small herds. With compact box sizes and lower loading heights, you’ll be amazed at the efficiency of our LS spreaders. Available in 3 models, the Nitro LS features a guillotine-style endgate, a reversible live apron floor, and our quick drop vertical beaters.
Apron Chain Limited Lifetime Warranty
Under the Apron Chain Limited Lifetime Warranty, Tubeline will replace a broken apron chain or connecting link on any Nitro model manure spreader. Restrictions may apply. For more information, please contact the Tubeline office.
Guillotine Endgate
The guillotine endgate can be opened partially to meter the amount of material being delivered to the beater assembly. This ensures the optimal delivery of lime and various manure consistencies to the field.
Other Standard Features
- Hydraulic-Driven Apron Chain
- Standard Rubber Seal Kit (Endgate & Front Panel)
- Apron Chain
- Galvanized Slats
- Quick Drop Beaters
- Replaceable Reversible Knives
- Robust and Dynamically Balanced
- Driveline Protection
- Industrial Jack
- High Load Bearings
| Specifications | Nitro 440LS |
|---|---|
| Carrying Capacity | 10 Ton |
| Heaped (cu. ft.) | 440 |
| Struck Level (cu. ft.) | 256 |
| Inside Dimensions (Inside width between flare 80.75") |
62"W x 31"D x 206.5"L |
| Overall Length | 27.5' |
| Overall Outside Width (Tandem Axle) | 107" |
| Loading Height (Tandem Axle) | 67" |
| Wheel Hub Capacity (Tandem Axle) | 8,000 lbs (8 bolt) x4 |
| Tandem Tire Sizes | 16.5-16.1 Implement425/22.5 Truck550/45-22.5 Flotation 11R-22.5 New or Used Truck |
| Beater Diameter | 32" |
| Beater Speed | 540 RPM |
| PTO Speed | 540 RPM |
| Apron Chain Link Dia. | 5/8" |
| Shipping Weight | 8,050 lbs. |
| Required Tractor PTO HP | 100 |
| Brakes Available | No |
Capacities determined by ASAE Sth S324.2
Paddle Kit
The optional bolt on paddle kit cups material to provide better throw.
LED Lights
LED lights and flashers ensure transit safety. Innovative light covers mechanically open and close in sequence with the end gate, ensuring lights are protected while spreading.
Optional Colours
In addition to the standard yellow, the Nitro lineup is available in red, green, blue and orange.
Enhanced Rubber Seal Kit
The Enhanced Rubber Seal Kit adds a U-shape compression seal to the front panel and the endgate to help contain semi solid materials.
Oscillating Ball Hitch
Optional on all models is the oscillating ball hitch available in various pin sizes.
Gate Indicator
With the gate indicator, you can quickly and easily see how open the endgate is from the seat of your tractor.
